特点
完全密封的定子绕组
155C 内部绕组温度持续能力
PTC 热敏电阻 (雪崩式) 过载保护
稀土钕铁硼磁体
转子磁体的自动防故障频带，兼容RoHS
UL, CE认证
可定制的转子轮毂尺寸
优势
和负载直接连接，消除了减速机、同步带和滑轮
零齿隙提供了更好的系统性能
消除了机器连接设备，降低了机器的整体尺寸
内置式电机使机器更为紧凑
大量的标准电机备选，并提供定制化服务，助您更快，更经济的研发您的机器
| KBM(S)机框尺寸 | 外径 | 通空直径 | 连续失速转矩 | 峰值失速转矩 | 额定输出功率 |
| KBM(S)-10 | 59.96 mm | 16.01 mm | 0.49 - 1.45 Nm | 1.17 - 4.91 Nm | 0.9 - 3.0 KW |
| KBM(S)-14 | 74.9 6mm | 20.01 mm | 1.22 - 2.92 Nm | 3.28 - 10.50 Nm | 0.9 - 3.0 KW |
| KBM(S)-17 | 84.96 mm | 30.01 mm | 2.06 - 6.20 Nm | 5.95 - 24.00 Nm | 0.9 - 3.0 KW |
| KBM(S)-25 | 109.96 mm | 50.01 mm | 4.85 - 11.1 Nm | 14.4 - 54.8 Nm | 0.9 - 3.0 KW |
| KBM(S)-35 | 139.96 mm | 65.01 mm | 12.4 - 25.9 Nm | 40.8 - 93.0 Nm | 0.9 - 3.0 KW |
| KBM(S)-45 | 189.96 mm | 85.02 mm | 29.7 - 54.6 Nm | 119 - 218 Nm | 0.9 - 3.0 KW |
| KBM(S)-43 | 159.78 mm | 76.28 mm | 6.11 - 44.2 Nm | 18.0 - 153 Nm | 0.9 - 3.0 KW |
| KBM(S)-57 | 202.90 mm | 104.17 mm | 18.8 - 109 Nm | 60 - 441 Nm | 0.9 - 3.0 KW |
| KBM(S)-60 | 229.85 mm | 105.05 mm | 29.4 - 154 Nm | 69.1 - 393 Nm | 8.4 - 20.1 KW |
| KBM(S)-79 | 259.63 mm | 152.43 mm | 43.5 - 222 Nm | 152 - 1075 Nm | 8.4 - 20.1 KW |
| KBM(S)-88 | 331.46 mm | 155.01 mm | 102 - 545 Nm | 197 - 1200 Nm | 8.4 - 20.1 KW |
| KBM(S)-118 | 361.11 mm | 225.04 mm | 172 - 672 Nm | 498 - 2400 Nm | 8.4 - 20.1 KW |
| KBM(S)-163 | 605.0 mm | 315.50 mm | 764 - 1329 Nm | 1966 - 3932 Nm | 8.4 - 20.1 KW |
| KBM(S)-260 | 850.0 mm | 557.85 mm | 1932 - 3445 Nm | 6494 - 12812 Nm | 8.4 - 20.1 KW |
